Technical Specifications of the Multiplaz 3500
| Process liquid for cutting and welding * |
|
Water |
|
| Process liquid for welding and soldering |
|
Water-Alcohol ** |
|
| Electrical Supply (single phase) |
V |
100 - 253 |
|
| Supply Frequency |
Hz |
50 - 60 |
|
| Maximum Power Requirement for network voltage 220 V |
kWt |
3.5 |
|
| Maximum Power Requirement for network voltage 110 V |
kWt |
2.0 |
|
| Welding type |
|
Plasma and plasma arc |
|
| Plasma flame temperature |
°F (°C) |
14400 (8000) |
|
| Cutting capabilities (regular steel) |
inch (mm) |
up to 3/8 (10) |
|
| Welding capabilities (regular steel) |
inch (mm) |
from 1/64 (0.4)
up to 2 (50) |
|
|
|
| Time of operation with one torch filling |
min |
20 - 30 |
|
| Torch Steam Pressure |
bar (pci) |
0.4 - 1.2 (5.7 - 17) |
|
|
|
| Power Unit Dimensions (l x h x w) |
inch |
15 x 7 1/2 x 5 1/2 |
|
|
|
| Power Unit Weight |
lbs (kg) |
17 1/2 (8) |
|
| Torch Dimentions, (l x h x w) |
inch |
8 x 7 1/2 x 2 1/2 |
|
|
|
| Torch Weight (dry) |
lbs (kg) |
2 (0.9) |
|
| Power Cable Length |
ft (m) |
6 1/2 (2) |
|
| Torch Cable Length |
ft (m) |
6 1/2 (2) |
|
* for some kinds of welding
** The manufacturer and distributors of the Multiplaz 3500 prohibit the use of Methyl hydrate due to its highly flammable properties, and the toxic fumes created. The manufacturer and distributor will assume no liability for effects on users who choose Methyl hydrate as a fuel source for the Multiplaz 3500.
